| Camera |
|
| Image Sensor |
1/3″ Progressive Scan CMOS |
| Min. Illumination |
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR |
| Shutter Speed |
1/25(1/30) s to 1/100,000 s |
| Lens |
4mm@ F2.0, Angle of view: 73.1 |
|
(2.8mm, 6mm, 12mm optional) |
| Lens Mount |
M12 |
| Day &Night |
IR cut filter with auto switch |
| Digital Noise Reduction |
3D DNR |
| Wide Dynamic Range |
Digital WDR |
| Angle Adjustment |
Pan:0° -355°, Tilt: 0° -65° |
| Compression Standard |
|
| Video Compression |
H.264/ MJPEG |
| H.264 Type |
BaseLine Profile/Main Profile |
| Video Bit Rate |
32Kbps~8Mbps |
| Dual Stream |
Yes |
| Image |
|
| Max. Resolution |
1280 x 960 |
| Frame Rate |
50 Hz5 fps (1280 x 720), 25 fps (704 x 576),25 fps (640 x 480) 60 Hz |
|
30 fps (704 x 576), 30 fps (640 x 480) |
| Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client |
| Network |
|
| Network Storage |
NAS |
| Alarm Trigger |
Motion detection, Dynamic analysis, Tampering alarm |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, |
|
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| Security |
User Authentication, Watermark |
| Standard |
ONVIF, PSIA, CGI, ISAPI |
| Interface |
1 RJ45 10M/100M Ethernet interface |
| General |
|
| Power Supply |
PoE (802.3af) |
| Power Consumption |
Max. 5 W (Max. 7 W with IR cut filter on) |
| Ingress Protection level |
IP66 |
| IR Range |
30 meters |
| Weight |
500g (1.1 lbs) |
