MikroBits Etna

Product Description

Spesifikasi Produk:

• Form Factor : 1U Rackmount
• Processor : Intel® Xeon® D Processor (2.7 GHz Quad Core)
• Chipset : SoC Integrated Intel® C220 Series
• Memory : 4 x R-DIMM/U-DIMM DDR4-2400 non-buffer non-ECC/ECC up to 128GB
• Memory installed : 2 x 8GB DDR4-2400 Industrial Grade ECC RAM
• BIOS : AMI (IPMI function)
• Storage : 4 x 2.5″ SATA HDD/SSD (RAID 0/1/5/10 supported), 1 x mSATA SSD (128GB installed)
• Network Interface : 4 x Gigabit Ethernet (Intel® i210), 2 x 10Gbe SFP+ (Intel® X552)
• Lan Bypass : 1 pair (port 3 & port 4)
• Lan Module : –
• Expansion Slots : 1 x PCIe x8
• Serial port : 1 console (RJ45 type)
• USB : 2 x USB 3.0
• Display : 1 x VGA
• LCDs : 1 x back lit 2character x16 character LCD Display
• LEDs : Power and HDD LED
• Power Supply : 320Watt redundant PSU 80+ Gold (87%~90% efficiency)
• Fan : 2x Redundant Chassis Fans,
• Dimensions : 44 mm (H) x 430 mm (W) x 391 mm (D)
• Weight (net/gross) : 8.5kg (18.74 lb) / 9.8kg (21.61 lb)
• Operating Temperature : 0°C ~ +40°C (32°F ~ 104°F)
• Storage Temperature : -20°C ~ +70°C (-4°F ~ +185°F)
• Humidity : 10% ~ 90% RH, non-condensing
• Operating System : Linux, Windows, Virtualization Host, FreeNas

Kelengkapan :

• 1 pcs MikroBits Etna
• 2 pcs Kabel Power
• 1 set Rackmount Bracket
