Mikrotik R52HND Wireless Minipci 400mW ABGN

Product Description

Spesifikasi

• Dual band IEEE 802.11a/b/g/n standard
• Output Power of up to 25dBm @ a/g/n Band
• Support for up to 2×2 MIMO with spatial multiplexing
• Four times the throughput of 802.11a/g
• Atheros AR9220, chipset
• High Performance (up to 300Mbps physical data rates and 200Mbps of actual user throughput) with Low Power Consumption
• 2 X MMCX Antenna Connector
• Modulations: OFDM: BPSK, QPSK, 16 QAM, 64QAM; DSSS: DBPSK, DQPSK, CCK
• Operating temperatures: -50�C to +60�C
• Idle power consumption 0.4W
• Max power consumption 7W
• MiniPCI IIIA+ design (3mm longer than MiniPCI IIIA)
• 1.5mm heatsink, 3mm RF shield thickness
• �15KV ESD protection on RF ports
