NetProtector Gigabit 8P 1U Rackmount

Product Description

Specification :

– Input voltage range : 9-30V
– LAN ports : 8 x 10/100/1000 Mbps (24 port max)
– LAN & PoE ports : 8 x 10/100/1000 Mbps (24 port max)
– Power socket : DC 2.1/5.5
– M6 mounting screw : 4 pcs
– Max voltage : 30V
– Max current : 11A
– Weight : 1.5 kg

Signal Path – pairs 1-2, 3-6 :
Rated Voltage : 5V
Maximum Voltage UC : 6V
Protection level line-line UP : ≤40V – 1 kV / ms, C3
Protection level line-PG UP : ≤600V – 1 kV / ms, C3
Nominal discharge current iN line-line : 20A – 10 / 1000μs, C3
Nominal discharge current iN line-PG. : 20A – 10 / 1000μs, C3

Track Supply – lines 4, 5 and 7, 8 :
Rated Voltage : 30V
Maximum Voltage UC : 36V
Nominal Current IN : 400mA
Nominal Discharge current iN line-line : 10 A – 10 / 1000ľs, C3
Nominal Discharge current iN line-PG. : 2kA – 8 / 20μs, C2
Protection Level line-line UP : ≤95V – 1 kV / ms, C3
Protection level line-PG UP : ≤1000V – 1,2 / 50μs, C2
