| Hardware Specification |
| Standards |
2.4GHz: IEEE802.11n, IEEE802.11g, IEEE 802.11b; |
| 5.0GHz: IEEE 802.11ac, IEEE 802.11n, IEEE 802.11a; IEEE802.3, IEEE802.3u |
| Interface |
1*10/100M WAN port; |
| 3*10/100M LAN ports |
| Antenna |
5x 5dBi External WiFi Antennas |
| Button |
1 Reset/WPS Button |
| 1 WiFi Button |
| Power |
Input: 100-240V—50/60Hz 0.3A |
| Output: DC 12V==1A |
| Dimensions |
153.2mm*153.2mm*40.04mm |
| LED |
1*Power, 1*SYS, 1*WAN, 3*LAN, 1*5G, 1*2.4G, 1*WPS |
| Wireless Features |
| Wireless Speed |
2.4G: 300Mbps; |
| 5G: 867Mbps; |
| Frequency |
Works over 2.4G and 5G concurrently |
| Basic Features |
Wireless: Enable/Disable; |
| SSID Broadcast: Enable/Disable; |
| Band: 2.4GHz, 5GHz; |
| Channel-2.4GHz: 1-13; |
| Channel-5GHz: 149, 153, 157, 161, 165; |
| Security |
Wireless MAC Address Filter (Wireless Access Control); |
| WEP, WPA-PSK/WPA2-PSK, WPA/WPA2; |
| Wireless Security: Enable/Disable; |
| WPS fast encryption; |
| Software Features |
| Internet Connection Type |
PPPoE |
| Dynamic IP |
| Static IP |
| Operating Mode |
Wireless Router Mode |
| Wireless AP Mode |
| Universal Repeater Mode |
| WISP Mode |
| WDS Mode |
| DHCP Server |
DHCP Server |
| DHCP Client List |
| DHCP Reservation |
| Virtual Server |
Port Forwarding |
| DMZ Host |
| UPnP |
| Security |
Client Filter |
| MAC Filter |
| Website Filter |
| Remote Web Management |
| VPN Pass-through |
Yes |
| Other |
Bandwidth Control |
| Guest Network |
| MAC Clone |
| DDNS |
| Traffic Statistics |
| Backup & Restore configurations |
| Firmware upgradeable via browser |
| Others |
| Temperature |
Operating Temperature: 0℃ ~ 40℃; |
| Storage Temperature: -40℃ ~ 70℃; |
| Humidity |
Operating Humidity:10% ~ 90% RH non-condensing; |
| Storage Humidity: 5% ~ 90%RH non-condensing. |
| Factory Defaul Settings |
IP Address: 192.168.0.1 |
| Login User Password: admin |
| Certificates |
CE, FCC, RoHS |
