Product Description
| HARDWARE FEATURES | |
|---|---|
| Interface | 4 10/100Mbps LAN Ports 1 10/100Mbps WAN Port |
| Button | Wireless On/Off Button, RE Button, WPS Button Reset Button, Power On/Off Button |
| Antenna | 3*9dBi Detachable Omni Directional Antenna (RP-SMA) |
| External Power Supply | 12VDC / 1.5A |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Dimensions ( W x D x H ) | 9.0 x 7.5 x 1.9 in. (227.5 x 190 x 48.3mm) |
| WIRELESS FEATURES | |
|---|---|
| Frequency | 2.4-2.4835GHz |
| Signal Rate | 11n: Up to 450Mbps(dynamic) 11g: Up to 54Mbps(dynamic) 11b: Up to 11Mbps(dynamic) |
| Reception Sensitivity | 450M: -71dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -91dBm@8% PER 6M: -89dBm@10% PER 1M: -97dBm@8% PER |
| Transmit Power | CE:<20dBm(2.4GHz) FCC:<30dBm |
| Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless | 64/128/152-bit WEP / WPA / WPA2, WPA-PSK / WPA2-PSK |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | WMM, Bandwidth Control |
| WAN Type | Dynamic IP/Static IP/PPPoE/ PPTP/L2TP/BigPond |
| Management | Access Control Local Management Remote Management |
| DHCP | Server, Client, DHCP Client List, Address Reservation |
| Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | DynDns, Comexe, NO-IP |
| VPN Pass-Through | PPTP, L2TP, IPSec (ESP Head) |
| Access Control | Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
| Firewall Security | DoS, SPI Firewall IP Address Filter/MAC Address Filter/Domain Filter IP and MAC Address Binding |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS, NCC, BSMI |
| Package Contents | 450Mbps Wireless N High Power Router RJ45 Ethernet Cable Power Adapter Quick Installation Guide Technical Support Card |
| System Requirements | Microsoft® Windows 10/8.1/8/7, XP, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
