Rp 2.105.000
Ubiquity AirMax Sectoral 15Bi 120° (2,4ghz 2X2 MIMO)
(Polarization : Dual Linear Vertical and horisontal)
Antenna sektoral terobosan baru dari Ubiquity dengant teknoloi AirMax 2×2 MIMO. dengan polarisasi vertikal dan horisontal sangat cocok dipasangkan radio yang suppot MIMO. Pigtail SMA sudah termasuk dalam satu paket Antena ini.
| Details AirMax Sectoral AM-2G15-120 : | |
| Frequency Range | 2.3 – 2.7 GHz |
| Gain | 15.0 – 16.0 dBi |
| Polarization | Dual Linear |
| Cross-pol Isolation | 28dB min |
| Hpol Beamwidth (6dB) | 123 deg |
| Vpol Beamwidth (6dB) | 118 deg |
| Elevation Beamwidth | 9 deg |
| Electrical Downtilt | 3 deg |
| Dimension | 700 x 145 x 93 mm |
| Weight | 4.0 Kg |
| Windload | 160 mph |
| Weight | 8000 kg |
|---|
Frequency Range-MHz 2300~2500 Bandwidth-MHz 83 Gain-dBi 24 Beamwidth in Hor. Plane 10 Beamwidth in Ver. Plane 14 F/B-dB ≥31 VSWR ≤2.0 Impedance-Ω 50 Polarization Vertical or Horizontal Maximum Power-W 100 Connector N Female or Customization Dimension-m 0.6 x 0.9 Weight-Kg … Continued
