Product Description
Product Specifications
• Dimensions: 77 x 77 x 28mm (3.03 x 3.03 x 1.1″)
• Weight: 110g (3.88oz)
• Networking Interface Speeds:
(1) GPON WAN, ITU G.984, 2.488Gbps downstream, 1.244Gbps upstream
(1) GbE LAN, 10/100/100Mbps
• Management Interface: In-Band Ethernet/PON
• Normal Optical Power Range:
TX (Class B+): 1.5 to 5dBm
RX: -8 to -28dBm
• Power Method:
Passive PoE (Pins +4,5;-7,8)
Dying Gasp Support
• Power Supply: PoE Adapter: 24V, 0.3A
• Max. Power Consumption: 7W
• Support Voltage Range: 20 to 28V
• Processor Specs: MIPS-32, 240MHz
• Buttons:
(1) Display Information
(1) Reset
• Operating Temperature: -10 to 45°C (14 to 113°F)
• Operating Humidity: 5 to 95% non-condensing
• Certifications: CE, FCC, IC
