Product Description
Product Specifications
• Dimensions: 76.5 x 76.5 x 26.4 mm (3.01 x 3.01 x 1.04″)
• Weight: 77 g (2.72 oz)
• Networking Interface Speeds: (1) GPON WAN, ITU G.984, 2.488 Gbps Downstream, 1.244 Gbps Upstream (1) GbE LAN, 10/100/1000 Mbps
• Management Interface: In-Band Ethernet/PON
• Normal Optical Power Range: TX (Class B+): 1.5 dBm to 5 dBm RX: -28 dBm to -8 dBm
• Power Method: Micro-USB: 5V, 1A 24V Passive PoE (Pins +4, 5; -7, 8)
• Power Supply: Micro-USB Power Adapter*: 5V, 1A
• Max. Power Consumption: 3.5 W
• Supported Voltage Range: 4.7 to 5.3V
• Processor Specs: MIPS32, 240 MHz
• Memory Information: 128 MB DDR3
• Buttons: (1) Reset
• Operating Temperature: -10 to 45° C (14 to 113° F)
• Operating Humidity: 10 to 90% Noncondensing
• Certifications: CE, FCC, IC
