Product Description
Product Specifications
• 443 x 221 x 43 mm (17.44 x 8.70 x 1.69 “)
• Weight:
Without Mount Brackets: 2.62 kg (5.78 lbs)
With Mount Brackets: 2.71 kg (5.97 lbs)
• Enclosure Characteristics: SGCC Steel
• Total Non-Blocking Throughput: 160 Gbps
• Switching Capacity: 320 Gbps
• Forwarding Rate: 238.10 Mpps
• Max. DC Power Consumption: 36W (Excludes SFP/SFP+ Modules)
• Power Method:
AC: 100-240VAC/50-60 Hz, Universal Input
DC: DC 56W, 25 to 16V, with 2.5 mm DC Power Inline Connector
• Supported Voltage Range:
AC: 100 to 240 VAC
DC: 25 to 16 VDC
Power: AC DC
100-240VAC/50-60 Hz, Universal Input DC
56W, 57 to 20V, with 48/24VDC Terminal Block
• LEDs Per Data Port: Speed/Link/Activity
• Networking Interfaces:
(12) 1/10 Gbps SFP+ Ethernet Ports
(4) 1/10 Gbps RJ45 Ethernet Ports
• Management Interface: (1) RJ45 Serial Port Out-of-Band, Ethernet Ports In-Band
• Certfications: CE, FCC, IC
• Rack Mount: Yes, 1U High
• ESD/EMP Protection:
Air: ±24 kV
Contact: ±24 kV
• Operating Temperature: -5 to 40°C (23 to 104°F)
• Operating Humidity: 5 to 95% Noncondensing
• Shock and Vibration: ETSI300-019-1.4 Standard
