Product Description
Model
O9
Ukuran
391.5*280*223mm
Deployment
Pole Mount
Application Scenarios
PtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance
Kisaran Frekuensi
5GHz
Compliant Standards
IEEE 802.11a/n/ac
Private TDMA Protocol
TD-MAX
Maximum Wireless Rate
867Mbps
Antarmuka
1*10/100/1000Mbps Ethernet Port
Antenna gain
23dBi
Beamwidth Antena
Horizontal: 10° Vertical: 10°
Tombol Atur ulang
1
Konsumsi Daya Listrik
7.5W
Tingkat Kedap Air
IP65
LED
PoE/LAN,LED1,LED2,LED3
Metode Daya Listrik
24V0.5A Passive PoE
Proteksi petir
6000V
Passive PoE
Passive power over ethenet via PoE/LAN (+4,5pins
-7,8pins )
Voltage range: 21-25V DC
-7,8pins )
Voltage range: 21-25V DC
Sensitivitas Penerimaan
11a 6Mbps -96dBm±1.5dBm
11n MCS7 HT20 -72dBm±1.5dBm
11ac MCS9 HT80 -65dBm±1.5dBm
11n MCS7 HT20 -72dBm±1.5dBm
11ac MCS9 HT80 -65dBm±1.5dBm
Mode Operasi
AP/Station/WISP/P2MP/WDS Repeater/Router
Enable/Disable Wireless Radio
Support
SSID Hidden
Support
Wireless Client isolation
Support
SSID Isolation
Support
Channel Bandwidth
20/40/80MHz
Channel Shift
Support
Wireless Access Control
Support
Weak Signal Client Limitation
Support
Daya Transmit
Adjustable power by 1dBm
WMM Capable
Support
APSD Capable
Support
Keamanan Nirkabel
64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Transparent Bridge
Support
VLAN Tagging for SSID
Support
Server DHCP
Support
Lintasan VPN
PPTP,L2TP
Akses Web Jarak Jauh
Support
Jadwal pengulangan sistem (Reboot)
Support
Waktu tunggu halaman
Support
Ping Watchdog
Support
DNS Dinamis
noip, dyndns.org
Diagnosis Jaringan
Ping, Traceroute, Signal Scan
Time&Date Setting
Support
Pembaruan Versi Firmware
Support
Backup/Restore Configuration
Support
Username Managerment
Support
Syslog
Support
Dikelola oleh Pengontrol
PC Software — CPE Assistant
Isi Paket
1*5GHz 11ac 23dBi Gigabit Outdoor CPE O9
1*PoE Power Adapter
1*Quick Installation Guide
1*PoE Power Adapter
1*Quick Installation Guide
Suhu Operasi
-30℃ ~ 60℃
Suhu Penyimpanan
-40℃ ~ 70℃
Kelembapan Operasi
10%~90% non-condensing
Kelembapan Penyimpanan
10%~90% non-condensing
Default IP
192.168.2.1
Nama Pengguna Masuk Default
admin
Kata Sandi Masuk Default
admin
Sertifikasi
FCC/CE/RoHS
.
