Product Description
Interfaces
| Ports | 24 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) 2 x 10/100/1000 Mb/s Gigabit SFP 1 x Ethernet (RJ45) (Console) |
Protocols
| Layer Services Supported | Layer 3 Support |
| Supported Protocols | Auto-VoIP IPv6 Port Mirroring |
| Queuing | Strict Priority, Weighted Round Robin (WRR) |
| MAC Address Table Size | 8K |
| VLAN Groups | 255 |
Security
| Security Features | Storm Control |
| Access Control List | 100 |
Standards
| RFC | RFC 2021 RFC 2030 RFC 2819 RFC 2865 RFC 2866 RFC 2868 RFC 2869 RFC 3579 RFC 3580 RFC 3164 |
| Supported IEEE Standards | 802.1ab, 802.1ak, 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.1x, 802.3, 802.3ab, 802.3ac, 802.3ad, 802.3u, 802.3x |
Performance
| Forwarding Rate | 38.69 Mpps |
| Switching Bandwidth | 52 Gb/s 26 Gb/s (Non-Blocking) |
| Priority Queues | 8 |
Electrical
| Power Draw | 25.00 W (Active) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Environmental
| Operating Temperature | 23 to 104°F / -5 to 40°C |
| Operating Humidity | 5 to 95% |
General
| Indicator Lights | Link/Activity/Speed |
| Dimensions | 17.4 x 8.7 x 1.7″ / 44.1 x 22.1 x 4.4 cm |
| Weight | 6 lb / 3 kg |
