Product Description
Interfaces
| Ports | 48 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) 2 x 10Gb SFP+ 2 x 10/100/1000 Mb/s Gigabit SFP |
Protocols
| Layer Services Supported | Layer 3 Support |
| Supported Protocols | Auto-VoIP IPv6 |
| MAC Address Table Size | 8K |
| VLAN Groups | 255 |
Security
| Access Control List | 100 |
Standards
| RFC | RFC 2021 RFC 2030 RFC 2819 RFC 2865 RFC 2866 RFC 2868 RFC 2869 RFC 3579 RFC 3580 RFC 3164 RFC 4541 RFC 5171 |
| Supported IEEE Standards | 802.1ab, 802.1ak, 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.1x, 802.3, 802.3ab, 802.3ac, 802.3ad, 802.3u, 802.3x |
Performance
| Forwarding Rate | 104.16 Mpps |
| Switching Bandwidth | 140 Gb/s 70 Gb/s (Non-Blocking) |
| Priority Queues | 8 |
Electrical
| Power Draw | 750.00 W (Active) |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| PoE per Port | 17 to 34.2 W |
Environmental
| Operating Temperature | 23 to 104°F / -5 to 40°C |
| Operating Humidity | 5 to 95% |
General
| Indicator Lights | Link/Activity/Speed, PoE |
| Rack Form Factor | 1 RU |
| Dimensions | 19.1 x 13.7 x 1.8″ / 48.5 x 34.8 x 4.5 cm |
| Weight | 12 lb / 5 kg |
